1255-0001-NWS New 2HP Spindle Motor w/Discs & Reversing Switch
1255-0001-NWS is a New 2HP Spindle Motor With New Stationary & Vari Disc Assemblies Including a Forward/Reversing Switch w/Cables.
- Motor Has a 1.180" Diameter Shaft @ 5.650" in Length.
Description:
The 1255-0001-NWS is a New 2HP Motor Which Comes With The Following:
- (1) 1255-0029 Motor Side Spring Vari Disc
- (1) 1255-0006 Stationary Motor Disc
- (1) 1255-0007 Stationary Pulley Key w/Pin
- (1) 1159-8154 Forward/Reversing Spindle Switch w/Cables
- Forward/Reversing Switch Is Included, and The New Stationary & Vari Disc Assemblies Are Mounted onto The Motor Shaft w/ Snap Ring & Set Screw and Are Ready For Installation Upon Arrival !
This Motor Will Fit The Following Machines:
- Series I Standard
- Series II Special
- Series I & II EZ Trak
This Motor WILL NOT Fit Rigid Ram CNC or V2XT CNC Machines to Purchase The 2HP CNC Spindle Motor with Discs Click Here.
Alternate Part Numbers:
255-0001-NWS
2550001-NWS
